PTZ Camera Systems Remote Camera Controller AW-RP60GJ
| Power Requirements | 12 V DC (10.8 V to 13.2 V) |
| PoE* | IEEE802.3af standard: 42 V to 57 V DC (Camera Input) |
| Current Consumption | 0.9 A (XLR connector input), 0.3 A (PoE power supply) |
| Mass | 1.5 kg (3.31 lbs) |
| Dimensions (W x H x D) (mm) | W 210 mm x H 92 mm x D 177 mm (excluding protrusions) |
| Dimensions (W x H x D) (inch) | 8-9/32 inches x 3-5/8 inches x 6-31/32 inches (excluding protrusions) |
| Display | 3.5-type liquid crystal (QHD 960 x 540) |
| Connection Specifications | No. of Connectable Cameras : 200 (IP), 5 (RS422) *Up to 100 for cameras other than the AW-UE150 Remote Camera Selection : 5 (6 to 200 controlled from the LCD) No. of Camera Groups : 40 (5 units/group) No. of Memory Presets : 100 |
| Note | *PoE is the abbreviation for Power over Ethernet. |
- Easy Usability, Quick Operation
– Equipped with a 3.5-type LCD Screen
– New Joystick with Enhanced Operability
– Advanced Camera Adjustment
– Flexible Customization Features
– PoE Support
https://pro-av.panasonic.net/en/products/aw-rp60gj/
If you are interested in our products or need detailed advice, please contact us at the contacts below.
Sales Department
Mob.: +7 747 47 00 950
Email: sales@mediashop.kz
Technical Support and Consultation Department
Mob.: +7 747 47 00 940
Email: Support@mediashop.kz
Or fill in the feedback form and we will contact you in a short time.
Related products
-
Read more
Connections
SDI Video Inputs
1
SDI Video Outputs
Automatically matches the HDMI video input.
HDMI 2.0 Video Inputs
1 x type A.
HDMI 2.0 Video Outputs
1 x type A.
SDI Rates
270Mb, 1.5G, 3G, 6G, 12G.
Multi Rate Support
Auto detection of SD, HD, 2K, Ultra HD and 4K.
Updates, Configurations and Power
USB Type‑C.
Reclocking
Yes
Power Requirements
Power Consumption
5W max.
Operational Voltage Range
4.4V to 5.25V DC
Environmental Specifications
Operating Temperature
0° to 40° C (32° to 104° F)
Storage Temperature
-20° to 60° C (-4° to 140° F)
Relative Humidity
0% to 90% non-condensing -
Read more
Conversion VGA/HDMI/SDI to 4K HDMI/3G-SDI, Multi-format Up/Down/Cross
Video Inputs 1x VGA, 1x HDMI, 1x HD/SD-SDI, 1x Reference Input
Loop Through —-
Video Outputs 1x SDI, 1x HDMI
Audio Inputs 2xRCA(Unbalanced Audio L/R), 2x SDI/HDMI Audio embedded
Audio Outputs SDI embedded audio up to 8CH, 48KHz, PCM audio, HDMI embedded audio up to 8CH, 48KHz, PCM audio
Audio Format Selection —-
Audio Gain —-
Supported Video Input Formats 2160p(23.98/24/25/29.97/30/50/59.94/60Hz), 1080p(23.98/24/25/29.97/30/50/59.94/60Hz),
1080psf(23.98/24/25/29.97/30Hz), 1080i (50/59.94/60Hz), 720p (50/59.94/60Hz),
625i, 576p, 576i, 525i, 480p, 480i, 1920×1080(60Hz), 1280×720(60Hz), 1600×1200(60Hz), 1400×1050(60Hz), 1366×768(60Hz), 1280×1024(60Hz), 1024×768(60Hz), 800×600 (60Hz)
Output Resolutions 2160p(23.98/24/25/29.97/30/50/59.94/60Hz), 1080p(23.98/24/25/29.97/30/50/59.94/60Hz),
1080psf(23.98/24/25/29.97/30Hz), 1080i (50/59.94/60Hz), 720p (50/59.94/60Hz),
625i, 576p, 576i, 525i, 480p, 480i
Equalizer Yes
Reclock Yes
SDI Cable Drive Yes
Updates and Configuration Mini USB x 1
Dimension (LxWxH) 220 x 143 x 42 mm
Weight 1 kg
Operating Temp. Range 0~40 °C
Power DC 12V, 9.4W
What’s in the Box 1 x DAC-45, 1 x AD Switch DC 12V. -
Read more
Model
SCH (SDI ⇌ HDMI Cross Converter)Input
1 X BNC 3G/HD/SD-SDI
1 X HDMI HDMIOutput
2 X BNC 3G/HD/SD-SDI
1 X HDMI HDMISDI Support Format
3G-SDI:1080P(60/59.94/50)
HD-SDI:1080P(30/29.97/25/24)
1080I(60/59.94/50)
1080PsF24
720P(60/59.94/50/30/25/24)HDMI Support Format
1080P(60/59.94/50/30/29.97/25/24)
1080I(60/59.94/50)
1080PsF24
720P(60/59.94/50/30/25/24)General
Power Consumption ≤4.2W
Input Voltage DC 5～24V
Connector DC 12V
Battery Plate F970 (Standard); D28S, E6 (Optional)
WorkingTemperature -20°C~60°C
Storage Temperature -30°C~70°C
Unit Size (mm) 108.5L×78.8H×23D
Unit Weight 230g/ 260g (With F970 Plate) -
Read more
Model
STH (SDI to HDMI Converter)Input
1 X BNC 3G/HD/SD-SDIOutput
1 X BNC 3G/HD/SD-SDI
1 X HDMI HDMISDI Support Format
3G-SDI:1080P(60/59.94/50)
HD-SDI:1080P(30/29.97/25/24)
1080I(60/59.94/50)
1080PsF24
720P(60/59.94/50/30/29.97/25/24)HDMI Support Format
1080P(60/59.94/50/30/29.97/25/24)
1080I(60/59.94/50)
1080PsF24
720P(60/59.94/50/30/29.97/25/24)General
Power Consumption ≤3W
Input Voltage DC 5～24V
Connector DC 12V
Battery Plate F970 (Standard); D28S, E6 (Optional)
Install Way 1/4″-20 Thread Socket
Working Temperature -20°C~60°C
Storage Temperature -30°C~70°C
Unit Size (mm) 98.8L×67.4H×22.8D mm
Unit Weight 180g/210g (With F970 Plate)
